Sedecal V

Sedecal V

The  Sedecal V variable height veterinary X-ray  system combines a four way floating tabletop and a height adjustable counterbalanced Canon tubehead with a powerful anatomically programmed generator for efficient high powered radiography.

    Features

    • Four way floating top table
    • Height adjustable and rotating tubehead
    • Foot operated electromagnetic locks
    • 17 inch colour touchscreen control
    • Over 300 preset anatomically programmed exposure factors
    • Touchscreen can be wall, tubehead or pedestal mounted
    • Dual focus Canon rotating anode tubehead

Downloads

Sedecal V
Sedecal V

Specifications

Tube support columnFixed
TubeheadAdjustable height
Tubehead rotationLockable +/- 90 degrees
TabletopFour way floating
Tabletop sizeStandard 1500 x 710mm, optional 1950 x 710mm
Table locksFoot operated electromagnets
DR panel holderUnder table
